Koso DB-03R Multifunction Plug & Play for Honda Grom

Koso North America

$259.95 USD

This product is available

Share:

DB-03R Multifunction Plug & Play for Honda GROM®

This plug & play DB-03R Multifunction is the perfect addition for your Honda GROM®. Its changeable blue, orange or purple backlight makes it very easy to read at night even at high speed. The integrated indicator lights provide all the necessary information for any street use. The RPM scale is perfect for the Honda GROM® engine. This instrument also features a gear indicator and shift light which will allow you to shift in the perfect gear. Beside those great functions, the DB‑03R Multifunction Plug & Play for Honda GROM® also features: speed, odometer, trip meter, RPM, temperature, volt, fuel level and a lot more ! Using the OEM sensors, this meter is very easy to install.

*Only fits Honda GROM® up to 2016*

Speedometer Display range: 0~360 km/h (0~225 MPH)
Display unit: km/h or MPH
Display internal <0.5 second
Odometer Display range: 0~99999 km (mile), reset automatically after 99999 km
Setting unit : 100 RPM
Trip meter A/B Display range: 0~999.9 km (mile), reset automatically after 999.9 km (mile).
Display unit: 0.1 km (mile).
Total hour meter Display range: 0~99999 H.
Display unit: 1 H.
Hour meter A.B Display range: 0.0~999.9 H.
Display unit: 0.1 H.
Tire circumference Setting range: 300~2,500 mm
Setting unit: 1 mm, Sensor point: 1~20
Tachometer Display range: 0~10,000 / 0~12,000 / 0~15,000 RPM.
Display unit:



  • 10,000 RPM-Each level represent 166 RPM
  • 12,000 RPM-Each level represent 200 RPM
  • 15,000 RPM-Each level represent 250 RPM
Display internal <0.5 second
The RPM Red, Yellow Setting range: 1,000~15,000 RPM
Shift light Setting unit: 100 RPM
Warning Light on (F-OFF)     Flash (F-ON)
MAX RPM record Display range: 0~10,000 / 0~12,000 / 0~15,000 RPM
The RPM input Setting range 0.5, 1~24
The RPM input pulse Setting range:



  • HI (The positive wave pulse)
  • Lo (The negative wave pulse)
Temperature unit Display unit: ºC or ºF
Thermometer Display range: 0.0~250.0°C (32.0~482.0°F)
Display internal <0.5 second
Over temp warning (Water temperature) Setting range: 60~250°C (140~482°F)
Setting unit: 1°C (°F)
Top temperature record Display range: 0~250°C (32~482°F)
Fuel meter Display range: 6 levels
Display unit: Each level represents 16.6%
Setting range: 100Ω, 250Ω, 510Ω, 1200Ω, SW
Clock 24 H
Volt meter Display range: DC 8~18 V.
Flashing warning when voltage lower than 11.5 V or higher than 15.5 v.
Backlight brightness Setting range: 1-5 (Darkest)~5-5 (Brightest)
Backlight color Setting options:



  • Blue, Orange or Light purple
Effective voltage DC 12V
Effective temperature range -10~ 60°C (14~ 140°F)
Meter standard JIS D 0203 S2
Meter size (W x L x H) 120 X 68.5 X 44.1 mm
Meter weight ±127.3 g
Indicator light color
  • Neutral (Green)
  • High beam (Blue)
  • Repeater (Green)
  • EOBD (Amber)
  • Oil (Red)
  • Temperature alarm (Red)
  • RPM shift light (Red, Yellow)
Gear position Display range :
N, 1, 2, 3, 4, 5, 6, 7, 8, 9
